Dental Care Bone Pet Injection Molding Machine for Dog Snacks

Name: Dental Care Bone Pet Injection Molding Machine for Dog Snacks
Brand: DARIN
Price: 1 USD

Brand Name : DARIN

Model Number : DM268

Certification : CE Certificate

Place of Origin : Jinan,Shandong Province

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 99 sets per year

Delivery Time : 45days

Packaging Details : We supply standard export wooden cases, suitable for long-term trips and mul-times loading & unloading by forklift. If needed, please extra pay for the packages.

Name : Dental Care Bone Pet Injection Molding Machine for Dog Snacks

Voltage : 380V, 50HZ

Power(W) : 89kw

Weight : 5000kg

Dimension(L*W*H) : 8.9 x 2.3 x 2.8m

Warranty : 12 months

Contact Now

Dental Care Bone Pet Injection Molding Machine for Dog Snacks

Product Specification

Darin's Dental Dog Treats/Dog Chews Snacks Injection Moulding Machine is our new research and development pet food machine. This is our unique product in pet food industry. The machine is full automatic and just need 2 workers to operate it easily. Also we have various moulds for your choice to meet the dog's interest requirement. The product is nutrition and health and the raw material is totally natural and beneficial for dog. The Mouldable dog treats can protect dog's teeth and oral cavity health.

Now in pet food industry, Dental Dog Treats/Dog Chews Snacks Injection Moulding Machine is very popular and demand increases every year. We have sold many machines running in USA, Holland, Italy, Spain, Czech and India, etc.

Contact me today and allow me to bring your idea to life.
We are dog lovers--we love bringing your ideas to market.

Technical Parameter

Item	Name of item	Unit	DM268B-I
Injection Unit	Screw Diameter	mm	55
	Screw L/D Ratio	Ratio	20
	Injection Volume (Theoretical)	cm	601
	Injection Weight (PS)	g	548
	Injection Pressure	Mpa	185.1
	Injection Rate into Air	g/s	223.7/276.1
	Injection Stroke	mm	256
	Injection Speed	Mm/s	95/116
	Screw Speed	rpm	201/246
Clamping Unit	Clamping Force	KN	2600
	Clamping Stroke	mm	550
	Space Between Tie-bars	mm×mm	580 x 580
	Max. Mould Height	mm	600
	Min. Mould Height	mm	250
	Ejector Stroke	mm	160
	Hydraulic Ejection	KN	68
	Ejector Rob Quantity	pcs	9
Others	Max. Pump Pressure	Mpa	17.5
	Pump Motor Power	kw	22/30
	Heater Power	kw	15.9
	Hopper Volume	L	50
	Oil Pump Volume	L	550
	Machine Weight	t	8.5
	Mould Positioning Ring Diam	mm	160
	Sphere Radius	mm	SR10
	Machine Dimension	m x m x m	5.82 x 2 x 2
